Classroom Training

W-L70

Sealing of Flanged Joints

Integrate the leak-tightness factor as of the design stage by using the appropriate procedures, knowing the properties of the seals and by applying the appropriate design analysis method

Objectives:

Upon completion of the training, the participants will be able to carry out the following:

  • describe the behaviour of a flanged joint fitted with a seal;
  • specify the leak-tightness solutions (flat seals for flanged joints) based on the conditions of use;
  • define standard practice for factoring leak-tightness into the design of flanged joints

Date:

19 November 2024 – 21 November 2024

Time:

15:30 – 18:30 (GMT+8) Singapore /
08:30 – 11:30 (GMT+1) France

Pre-requisites:

None

Pedagogical means:

Theory and laboratory demonstrations. AR

Who should attend:

Engineers and technicians from Design departments, manufacturers and suppliers of seals, Quality departments, designers of pressurized equipment, project owners.

Course Outline:

  • Theory of leak-tightness
    • Units
    • Conversion
    • Orders of magnitude.
  • Flanged joints:
    • Parameters that affect sealing.
  • Handling and checking the tightening process:
    • Tightening procedures.
    • Tools.
    • Accuracy and dispersion of tightening.
  • Seals:
    • Description of the main categories of seals.
  • Placing and replacing a seal.
  • Leak measurement techniques.
  • Characterisation of flat seals:
    • Standards.
    • Customer procedures.
  • Calculations for flanged joints:
    • Analytical calculation principle based on the Taylor Forge method (Codap®, Codeti®, EN 13445, EN 13480, ASME, PD5500, etc.).
    • Principle of design analysis based on the method EN 1591 and presentation of the Cetim 1591 software.
    • Principle of design analysis of finished elements.
  • Laboratory demonstration on flanged joints (tightening and leak-tightness measurement).

Trainer:

This course will be conducted by Mr. Stéphane JAVANAUD, engineer specialising in the field and providing consultancy services and technical assistance to businesses.

Mr. Stéphane JAVANAUD

Graduated from Ecole Nationale Supérieur d’Ingénieurs de Bretagne Sud (ENSIBS), France 2016 Experience in the field of bolted flange joints, elastomeric seals and Finite Element Analysis.

Areas of Expertises

Engineer in the sealing technologies Cetim’s Lab since 2016.

Gasket testing: definition of test procedures for gasket characterization and qualification for gasket manufacturers and end-users in the field of Oil & Gas, Nuclear and chemical industry

Bolted flange connection calculation:

Training for industry on bolted flange joints and EN1591 calculation method

Publications

Materials and Design volume 156 (2018): Temperature-dependent modelling of a HNBR O-ring seal above and below the glass transition temperature. (https://doi.org/10.1016/j.matdes.2018.06.016).

ASME PVP 2018: Flange Gasket Behavior Characterization for Service in Arctic Environment (PVP2018-84284).

Profile

Graduated from Ecole Nationale Supérieur d’Ingénieurs de Bretagne Sud (ENSIBS), France 2016

Experience in the field of bolted flange joints, elastomeric seals and Finite Element Analysis.

Course Name:

W-L70: Sealing of Flanged Joints

Course Date:

19 November 2024 – 21 November 2024

Time:

15:30 – 18:30 (GMT+8) Singapore /
08:30 – 11:30 (GMT+1) France

Closing Date:

5 November 2024, Tuesday

Course Fee:

SGD 900.00 per person (exclude GST)

We welcome groups to attend our trainings. Please contact us for a group discount package.

Our Accounts will advise if GST is applicable. Participants shall bear all bank charges.

Learners must fulfill at least 75% attendance and pass all assessment components, to be awarded with a Certificate of Attendance (COA).

For clarification or inquiries please contact Mrs Lorraine HUANG at +65 67788285 or send an email to training@cetim-matcor.com

Registration Form

To register for the course, please complete this form.

Payment Details:

  • Registration form and course fees are to reach MATCOR before the closing date.
  • Registration will only be confirmed upon full payment.
  • Direct internet banking payment to MATCOR Technology & Services Pte Ltd, Bank: Development Bank of Singapore, Bank Code: 7171, Branch Code: 032, Swift Code: DBSSSGSG, Bank Address: 1 Kim Seng Promenade, #02-32, Great World City, Singapore 237994, Account / Iban No: 032-004152-3. / PAYNOW: UEN199201190R
  • All cheques should be made payable to “MATCOR Technology & Services Pte Ltd” and mailed to 3 Seletar Aerospace Link Singapore 797550, Or
  • Overseas participants may choose to pay in EUR or USD.
  • Participants shall bear all bank charges for payments.

For clarification or inquiries please contact Mrs Lorraine HUANG  at +65 67788285 or send an email to training@cetim-matcor.com

Cancellation & Refund:

  • Any cancellation made after closing date – no refund, but delegate substitution is allowed.
  • Any cancellation made before closing date will receive full refund.
  • MATCOR reserves the right to cancel or reschedule the course, only if deemed necessary
